Main Specifications：
| Model | Capacity | Readability（d） | Repeatability | Linearity | Max. O/T | e=10d | Temp. | Humidity |
|---|---|---|---|---|---|---|---|---|
| JD-R12W | 120g/600ct | 0.1mg/0.001ct | ±0.1mg | ±0.2mg | 120g/600ct | 1mg | 18-23℃ | (50-70)%RH |
| JD-R22W | 220g/1100ct | 0.1mg/0.001ct | ±0.1mg | ±0.2mg | 220g/1100ct | 1mg | 18-23℃ | (50-70)%RH |
| JD-R22Q | 220g/1100ct | 1mg/0.01ct | ±1mg | ±2mg | 220g/1100ct | 10mg | 15-30℃ | (40-80)%RH |
| JD-R32W | 320g/1600ct | 0.1mg/0.001ct | ±0.1mg | ±0.2mg | 320g/1600ct | 1mg | 18-23℃ | (50-70)%RH |
| JD-R32Q | 320g/1600ct | 1mg/0.01ct | ±1mg | ±2mg | 320g/1600ct | 10mg | 15-30℃ | (40-80)%RH |
| JD-R52Q | 520g/2600ct | 1mg/0.01ct | ±1mg | ±2mg | 520g/2600ct | 10mg | 18-23℃ | (50-70)%RH |
| JD-R62Q | 620g/3100ct | 1mg/0.01ct | ±1mg | ±2mg | 620g/3100ct | 10mg | 18-23℃ | (50-70)%RH |
Main Characteristic：
| Sensor Type | Electromagnetic (EMFC) | |||
|---|---|---|---|---|
| Calibration Way | Fully Automatic Internal CAL(User-set time and temperature to trigger out the calibration automatically) | |||
| Anti-vibration | Adjustable wave filter intensity function | |||
| Housing | Fully Aluminum + ABS | |||
| Display | VATN Backlit LCD Display | |||
| Stable time | 3-10s Adjustable | |||
| Unit | g, mg, ct, oz, ozl, dwt, GN, lb, N, dr,tlT, tls, tlH,T(Tola), T/A/R(tola/anna/rati), /A/R(tola/Mna/rati), ms(Mesghal), bat, /lb(Partsper pound),kg,20units selectable | |||
| Interface | RS232 | |||
| Weighing Mode Lock | Weighing Mode Lock Automatically | |||
| Underhook | Fit with Underhook | |||
| housing size with sheild | 340x215x315mm | |||
| Plate Size | φ90mm | |||
| Power Supply | AC220V±10%, 50.60Hz | |||
