Main Specifications：
| Model | Capacity | Readability（d） | Repeatability | Linearity | Max. O/T | e=10d | Temp. | Humidity |
|---|---|---|---|---|---|---|---|---|
| JD-R102Q | 1020g/5100ct | 1mg/0.01ct | ±1mg | ±2mg | 1020g/5100ct | 10mg | 18-23℃ | (50-70)%RH |
| JD-R152Q | 1520g/7600ct | 1mg/0.01ct | ±1mg | ±2mg | 1520g/7600ct | 10mg | 18-23℃ | (50-70)%RH |
| JD-R202Q | 2020g10100ct | 1mg/0.01ct | ±1mg | ±2mg | 2020g10100ct | 10mg | 18-23℃ | (50-70)%RH |
Main Characteristic：
| Sensor type | Electromagnetic (EMFC) | |||
|---|---|---|---|---|
| Calibration Way | Fully Automatic Internal CAL(User-set time and temperature to trigger out the calibration automatically) | |||
| Anti-vibration | Adjustable wave filter intensity function | |||
| Housing | Fully Aluminum + ABS | |||
| Display | VATN Backlit LCD Display | |||
| Stable time | 3-10s Adjustable | |||
| Unit | g, mg, ct, oz, ozl, dwt, GN, lb, N, dr,tlT, tls, tlH,T(Tola), T/A/R(tola/anna/rati), /A/R(tola/Mna/rati), ms(Mesghal), bat, /lb(Partsper pound),kg,20units selectable | |||
| Interface | RS232 | |||
| Weighing Mode Lock | Weighing Mode Lock Automatically | |||
| Underhook | Fit with Underhook | |||
| housing size with sheild | 340x215x315mm | |||
| Plate Size | φ120mm | |||
| Power Supply | AC220V±10%, 50.60Hz | |||
